Management of a single implant in the esthetic zone

The treatment plan was as follows:

• Extraction of tooth #9 and socket preservation
• Three-month healing period
• Placement of implant #9 and connective tissue graft
• Three-month healing period
• Implant #9 exposure, placement of healing abutment and connective tissue graft
• Three-month healing period
• Final implant #9 crown restoration

Extraction and socket preservation of tooth #9

After oral sedation with 0.25 mg triazolam one hour prior to surgery and local anesthetic induction using 2 per cent lidocaine with 1:100,000 epinephrine and 0.5 per cent bupivacaine with 1:200,000 epinephrine, a sulcular incision was made circumferentially around tooth #9. The remaining root was extracted atraumatically using a piezoelectric periotome device (Fig. 2).

Thorough degranulation of the extraction site with a pear-shaped carbide finishing bur and Prichard curette proceeded. No dehiscence or fenestration was detected. Freeze-dried bone allograft (FDBA) was used to obliterate the extraction socket.

A bioabsorbable collagen plug (CollaPlug, Zimmer Dental, Carlsbad, CA, USA) was used to cover the graft. The area was secured using 4-0 expanded polytetrafluoroethylene (ePTFE) suture (Fig. 3). The restorative dentist temporized space #9 with an interim removable partial denture.

After three months of uneventful healing (Fig. 4), Stage 1 implant placement was initiated.

#9 fixture placement and connective tissue graft

After oral sedation with 0.25 mg triazolam and local anesthetic induction using 2 per cent lidocaine with 1:100,000 epinephrine and 0.5 per cent bupivacaine with 1:200,000 epinephrine, a flap was created using a trapezoidal papilla-sparing incision design that involved a palatally oriented crestal incision over the #9 site with two vertical releasing incisions made on the buccal, both avoiding the mesial and distal papillae.

A full-thickness flap was raised past the mucogingival junction. Degranulation of the site with a pear-shaped carbide finishing bur and Neumeyer bur revealed adequate apico-coronal, bucco-lingual and mesio-distal dimensions for implant placement.

After osteotomy preparation, a rough-surfaced, internal hex 4 mm (diameter) by 13 mm (length) implant was placed into the filled site (NanoTite Parallel Walled Certain Implant, BIOMET 3i, Palm Beach Gardens, FL, USA) (Fig. 5).

Primary stability was achieved, and a cover screw was placed. In order to form an esthetic soft-tissue profile by expanding mucosal dimensions, a connective tissue graft was harvested from the palate and placed on the buccal aspect of the ridge overlying the implant. The graft was stabilized using 5-0 chromic gut sutures (Fig. 6).

After periosteal release via lateral scalpel incisions, the flap was primarily closed with 4-0 ePTFE sutures in an interrupted and horizontal mattress fashion (Fig. 7). The area was re-temporized with a resin-bonded fixed partial denture.

Implant exposure with connective tissue graft

The #9 site healed well and without incident after three months (Fig. 8). After using a tissue punch technique to remove the mucosa immediately coronal to the fixture (Fig. 9), a one-piece 4.1 mm (platform) by 5 mm (emergence profile) by 4 mm (height) healing abutment (Certain EP Healing Abutment, BIOMET 3i, Palm Beach Gardens, FL, USA) was placed on the #9 implant.

To further augment the buccal ridge dimension, another connective tissue graft was harvested from the palate. A pouch-like envelope flap was raised over the labial ridge aspect into which the connective tissue was transplanted and fixed using 5-0 chromic gut suture (Fig. 10). The healing abutment remained exposed. A periapical radiograph revealed sufficient bone height around the fixture (Fig. 11). The resin-bonded fixed partial denture was replaced.

Final prosthetics

Final restoration of the #9 implant was performed three months post-exposure (Fig. 12). The marginal height and contour of the #9 implant crown matched that of adjacent tooth #8, and a periapical radiograph showed suitable peri-implant bone height (Fig. 13). The patient was satisfied with the functional and esthetic result (Fig. 14).

Postoperative instructions

After each surgical procedure, the patient was instructed to take ibuprofen 600 mg every 4-6 hours, hydrocodone 7.5 mg/acetaminophen 750 mg every 4-6 hours for pain and doxycycline 100 mg qd for 10 days.

The patient was instructed not to brush at or near the surgical site but instead to rinse with 0.12 per cent chlorhexidine or warm saline twice daily. The patient was also directed not to chew in the affected area for at least two weeks. Suture removal occurred at 10 to 14 days post-surgery.
